Complete Vertical Seeding Line — Drum Type
Model:
600-1200 trays/hr
Drum type
≥97% accuracy
Complete Vertical Seeding Line — Drum Type
A premium turnkey solution integrating soil loading, substrate filling, drum seeding, soil covering, and watering in a vertical configuration. Designed fo...
Price Available on Request
Production Capacity
600–1,200 trays/hour
Seeding Accuracy
≥97%
Seed Diameter Range
0.3–3.0 mm
Total Power
3 kW / 220V
✓ 2-Year Warranty
✓ Global Shipping
✓ CE Certified
Complete Vertical Seeding Line — Drum Type
A premium turnkey solution integrating soil loading, substrate filling, drum seeding, soil covering, and watering in a vertical configuration. Designed for high-volume nursery operations.
Line Components
- Soil loading and substrate filling machine
- Pneumatic drum precision seeder (2BS-6H)
- Soil covering & watering machine (FTH)
- Conveyor system with tray indexing
- Control panel with one-touch operation
Production Capacity
600–1,200 trays/hour with ≥97% seeding accuracy and ≤3% missing-hole rate
| Technical Parameter | Value |
|---|---|
| Model | 2BS-6-1 |
| Structure Type | Pneumatic Drum Type |
| Dimensions (L×W×H) mm | 8000×2500×2500 mm |
| Machine Weight | 800 kg |
| Missing-Hole Rate | ≤3% |
| Applicable Tray Cells | 50/60/72/105/128/200-cell |
| Operating Voltage | 220V |
Vegetable Nursery
Tomato, pepper, cucumber, eggplant and leafy greens with 0.3–3.0 mm seeds
Flower Production
Petunia, pansy, begonia and fine ornamental seeds for commercial greenhouses
Tobacco Seedling
Ultra-fine tobacco seeds (0.3 mm) with highest precision and lowest missing-hole rate
